2017-01-29

Pilot/Namiki Nibs

the following photo shows the size of different current Pilot/Namiki nibs,



here is a old photo without the #30 nib



SizeWeight
3 0.38g
5 0.53g
10 0.62g
15 0.70g
20 0.78g
50 2.03g

Namiki #20 nib is the same size as Pilot #15, but with different shape and
feed. Namiki nibs usually carry the PP-F hallmark as follows,



Most Pilot/Namiki nibs have date code stamped in the format of "XMMYY", "XMYY", "MMYY" or "MYY"

X is a alphabet, e.g. "A", "B", "a", "b", "H", "T" ...
"H" was the Hiratsuka factory 平塚工場, and "T", Tokyo factory 志村工場 (opened Dec 1935, renamed to Tokyo factory May 1966, moved Nov 1978), was closed for some time. these two alphabets are no longer use today. "A" and "B" mark the different welding machines in the Hiratsuka factory.

MM or M is single or double digit denotes the month.

YY is the year, e.g. 09 is 2009.

some older nibs would also has the old JIS mark.

more info:
Bruno Taut: Datation of Japanese Pens. II. Pilot Nibs
Bruno Taut: Datation of Japanese Pens. III. Pilot’s Pen Bodies
http://taka215.blog63.fc2.com/blog-entry-65.html,
http://www.lionandpen.com/Dutcher/JIS.html

since 2010, the first alphabet is omitted.



from the catalog of Namiki, there are several varieties of Namiki nibs,
Two tone 18k #50: for Emperor collection and Chinkin collection (large size)
Two tone 18k #20: for Yukari Royale collection and Chinkin collection (medium size)
Two tone 18k #10: for Yukari collection
Single tone 18k #50: for Urushi collection (large size)
Single tone 18k #20: for Urushi collection (medium size)
Single tone 14k #10: for Nippon Art collection (FN-5M)
Single tone 14k #5: for Nippon Art collection (FN-35SM)


2017-01-21

Pilot Custom



we have a new member for the Pilot Custom family, the Custom Urushi with #30 nib,

from the left, Custom Urushi, 845, 823, 743, 742, 74, 912, 91 and 92






the higher end models have thicker bands and trims.

the nibs:
modelgoldsizecolorEFFSFFMSFMMSMBBBCMSPOFAWASU
Urushi18k30two tone

Y

Y
Y





84518k15two tone
Y


Y
YY





82314k15single tone
Y


Y
Y






74314k15single toneYYYYYYYYYY
YYYY
74214k10single toneYYYYYYYYYYYYYYY
7414k5single toneYYYYYYYYYYY



91214k10single tone rhodium platedYYYYYYYYYYYYYYY
9114k5single tone rhodium platedYYYYYYYYY



9214k5single tone rhodium platedYY
Y
Y











all can use the CON-70 converter except 823 and 92.

the dimensions are as follows
Modellength (mm)pen length (mm)diameter (mm)weight (g)pen weight (g)
with CON-70 except 823 and 92
Urushi155.0140.220.042.9424.91
845146.3132.215.928.3116.75
823148.4131.215.728.6818.87
743148.0131.615.725.5115.77
742145.8127.915.723.7414.82
74143.1125.614.721.2213.26
912140.5125.115.724.2815.33
91137.9122.814.721.2913.26
92136.8122.214.719.9511.99

the diameter are measured at the pen cap band.

Comparison of the feeds for the #30, #15, #10 and #5 nibs,
